FLATBEDS

//FLATBED TRUCK BODIES

PJ’s Truck Bodies & Equipment Co. takes pride in our flatbeds, having refined our design before expanding into other body types. Our flatbeds offer impressive flexibility, accommodating a range of needs from light to heavy-duty applications. With interchangeable floors and understructures and lengths ranging from 8 to 30 feet, we provide customizable solutions to fit various requirements. This focus on adaptability and precision in our flagship product underscores our commitment to delivering high-quality, tailored truck bodies.

//FIND THE RIGHT FLATBED FOR YOU

PJ’s Truck Bodies & Equipment Co. is dedicated to delivering tailored solutions for truck bodies, ensuring that each customer gets exactly what they need. Whether it’s a standard feature or a custom option, our experienced sales staff is well-equipped to help clients make the best choice for their specific requirements and budget. Our focus on customization and quality provides  a high level of service and expertise in the flatbed truck body market. If you’re in the market for a truck body,  PJ’s would be a great place to explore your options.

//SPECIFICATIONS

LONGSILLS:                          Non-Dumping Flatbed, 16' & smaller - 6" structural channel

                                    Non-Dumping Flatbed, 17' & larger - 7" structural channel

                                    All Dumping Flatbeds - 7" structural channel


CROSSMEMBERS:               3" structural channel, 12" on center, Class 5 chassis & smaller

                                               4" structural channel, 12"  on center, Class 6 chassis & larger


FLOORS:                                3/16" smooth steel

                                               (1) piece floor up to 16', pieced floor 17' & larger


POCKETS & RUB RAIL:       5" 11 guage formed channel side wraps, Class 5 chassis & smaller

                                               3" X 4" structural angle side wraps, Class 6 chassis & larger



                                               RUB RAIL - 3/8" X 2-1/2" flatbar


HEADBOARD:                      11 gauge smooth steel, 3/16" formed channel uprights


OVERALL WIDTH:               96" standard width option for 102" wide


PAINT:                                  Black Powder Coat, Standard  w/ additional color options


ADDITIONAL FEATURES:   LED Lighting, Back-Up Alarm, Mud Flaps
